Siemens LOGO! TD 6ED1055-4MH00-0BA0 Text Display Panel BD

Description

The Siemens LOGO! TD Text Display Panel (6ED1055-4MH00-0BA0) is an intuitive, compact operator terminal engineered specifically to extend the user interface of Siemens LOGO! 0BA6 logic modules. Featuring a high-contrast 4-line LCD display with adjustable 3-color backlighting (white, green, orange), this text display allows machine operators to monitor process statuses, view active alarm notifications, adjust timer settings, and alter counter thresholds remotely from the cabinet door.

Equipped with 6 tactile system navigation keys and 4 tactile, freely assignable function keys, the LOGO! TD replicates and expands upon the built-in display of LOGO! basic units. Connected via a dedicated serial communication cable, it enables convenient external panel door mounting while keeping main controller logic safe inside the enclosure. For machine builders, panel fabricators, and maintenance technicians in Bangladesh, this unit offers an economical display terminal that simplifies daily equipment operation without requiring complex graphics software programming.

Key Features

• 4-Line High-Contrast Text Screen: Displays up to 24 characters per line for clear diagnostic messages, timer values, and system warnings.
• 3-Color Backlight Indication: Configurable backlighting colors (white, green, orange) allow visual color-coded alarm state tracking.
• 10 Tactile Control Keys: Features 6 standard operator keys for menu navigation plus 4 freely assignable function keys ($F1$ to $F4$).
• Wide Supply Voltage Range: Flexible power supply terminal accepting 12V DC, 24V DC, or 24V AC inputs.
• LOGO! Soft Comfort Engineering: Easy message text assignment and parameter linking configured directly within Siemens LOGO! Soft Comfort software.

Technical Advantages

• High Efficiency: Instantaneous screen refresh rates and direct processor communication allow immediate operator adjustments.
• Durable Construction: Industrial IP65 front faceplate protects internal electronic components against dusty, humid plant door environments.
• Safety Protection: Built-in password levels and clear text alarm displays prevent unauthorized operator parameter tampering.
• Energy Saving: Low operating power consumption ($0.6 \text{ W}$ typical) minimizes active electrical load inside control panels.
• Easy Maintenance: Standardized cabinet door cutout and included serial interface connection cable ensure fast installation.

Applications

• Industrial: Small conveyer controls, plastic sealing jigs, chemical dosing pumps, and pneumatic assembly stations.
• Factory: Textile machine auxiliaries, garment processing units, packaging machine retrofits, and small air compressor boxes.
• Commercial: Automatic building lighting, booster pump stations, HVAC fan controls, and generator transfer panels.
• Project Installation: Compact control cabinet builds, OEM machine retrofitting, and LOGO! PLC operator interface additions in BD.

Why Choose This Product?

• Reliability: Manufactured to Siemens’ rigorous industrial engineering standards for continuous 24/7 duty cycles.
• Performance: High key tactile response, clear character rendering, and seamless communication with LOGO! 0BA6 units.
• Cost Effectiveness: Delivers essential text visualization and key inputs at a budget-friendly price point without requiring expensive graphics HMIs.
• After-Sales Value: Supported by genuine product verification, checking warranty guarantees, and prompt delivery through LOOP Shop in BD.

Technical Specification Table

Features List

✓ 4-line LCD character text screen with adjustable 3-color backlighting

✓ 10 tactile membrane keys including 4 user-assignable function keys ($F1$ to $F4$)

✓ Direct serial interface connection cable for LOGO! logic modules

✓ Wide input power compatibility (12V DC, 24V DC, or 24V AC)

✓ Heavy-duty IP65 dust-tight and splash-proof front bezel

Benefits For Customers

• Saves Cabinet Space: Compact dimensions ($128.2 \text{ mm} \times 86 \text{ mm}$) fit easily on small control box doors.
• Reduces Panel Costs: Eliminates the expense of graphical HMI panels for applications that only require text monitoring.
• Improves Operator Clarity: Color-changing backlights instantly alert operators to active system faults or warnings.
• Suitable for Bangladesh Environment: Rugged IP65 front face protects against dusty, humid, and warm factory environments in BD.

Installation & Maintenance Guide

Installation Requirements:

1. Prepare a clean panel door cutout measuring $119.5 \text{ mm} \times 78.5 \text{ mm}$.
2. Insert the front rubber sealing gasket properly around the bezel channel to maintain its IP65 moisture rating.
3. Insert the LOGO! TD unit into the cutout and tighten all cabinet mounting clamps evenly.
4. Wire a 12V/24V DC or 24V AC power line to the terminals and plug in the serial cable to the LOGO! CPU module.

Maintenance Tips:

• Gently clean the front display face using a soft, dry, non-abrasive microfiber cloth.
• Avoid using harsh chemical solvents, alcohol, or abrasive pads on the display surface.
• Periodically check terminal block screws and serial connection latches inside vibrating control boxes.

Safety Instructions:

• Always disconnect main control panel power before making wiring connections or dismounting the text display.
• Ensure correct power polarity on DC supply terminals to avoid damaging internal power circuitry.

Frequently Asked Questions (FAQ)

Q: What is the price of Siemens Logo 6ED1055-4MH00-0BA0 Text Display in Bangladesh?

A: The current sales price of the Siemens LOGO! TD (6ED1055-4MH00-0BA0) in BD is listed on loopshop.com.bd. Contact us directly or check our store for live stock and pricing details.

Q: Where can I buy Siemens Logo 6ED1055-4MH00-0BA0 Text Display in Bangladesh?

A: You can purchase the genuine Siemens LOGO! TD panel online directly from loopshop.com.bd with secure courier delivery across all districts in Bangladesh.

Q: What warranty does this product have?

A: It comes with a standard testing and checking warranty from LOOP Shop to confirm full working condition upon delivery.

Q: Is this suitable for Bangladesh climate?

A: Yes, featuring an IP65 dust- and water-resistant front bezel and an operating temperature threshold up to 55°C, it is well suited for industrial conditions in BD.

Q: How to install this product?

A: Cut the designated panel opening ($119.5 \text{ mm} \times 78.5 \text{ mm}$), insert the unit with its sealing ring, secure mounting clamps, wire power supply terminals, and connect the serial communication cable.

Q: Which Siemens LOGO! units are compatible with the 6ED1055-4MH00-0BA0 Text Display?

A: This model is designed specifically for compatibility with Siemens LOGO! 0BA6 series logic modules via serial communication.

Q: Which software is used to configure message texts for the LOGO! TD?

A: Message texts, backlight colors, and function keys are configured using Siemens LOGO! Soft Comfort software.

Q: Does the LOGO! TD require a separate power supply?

A: Yes, it requires an external 12V/24V DC or 24V AC power feed connected to its rear terminal block.

Q: What are the panel cutout dimensions for the LOGO! TD?

A: The required cabinet door cutout measures $119.5 \text{ mm} \text{ (width)} \times 78.5 \text{ mm} \text{ (height)}$.

Q: Does LOOP Shop provide courier delivery outside Dhaka?

A: Yes, LOOP Shop delivers industrial automation equipment to Gazipur, Savar, Narayanganj, Chittagong, and all other industrial zones across Bangladesh.
