Siemens KP1500 Comfort HMI 15″ Key Panel 6AV2124-1QC02-0AX1 for PLC

Description

The Siemens SIMATIC HMI KP1500 Comfort Panel (6AV2124-1QC02-0AX1) is a premium 15-inch widescreen operator terminal engineered for large-scale industrial visualization and control tasks. Equipped with a high-resolution TFT display alongside a robust physical membrane keypad, this key panel combines wide-angle visual clarity with tactile button feedback, ensuring precise manual operator entry in heavy industrial environments.

Featuring dual-protocol networking with built-in PROFINET (Ethernet) and MPI/PROFIBUS DP interfaces, the KP1500 Comfort connects effortlessly to Siemens SIMATIC S7 controllers and enterprise automation networks. In Bangladesh’s heavy manufacturing, chemical, and textile sectors, where continuous machine uptime is critical, the KP1500 Comfort serves as a central control interface for monitoring complex SCADA screens, managing live alarm archives, and maintaining plant productivity.

Key Features

• Large 15-Inch Widescreen Display: High-definition 15″ TFT screen rendering rich process graphics, trend charts, and system diagnostic windows.
• Integrated System Keypad: Ergonomic membrane keyboard featuring numeric, alphanumeric, and programmable function keys for fast manual inputs.
• Multi-Protocol Fieldbus Support: Dual communication interfaces including PROFINET (Ethernet) and MPI/PROFIBUS DP for flexible network architecture.
• TIA Portal Configurable: Configurable using WinCC Comfort V11 SP2 or as successor model 6AV2124-1QC02-0AX1 from WinCC V14 SP1 onwards.
• Industrial IP65 Front Face: Heavy-duty front panel sealing protects internal logic components against dust ingress and liquid splashes.

Technical Advantages

• Durable Construction: Industrial-grade housing absorbs heavy mechanical vibration, thermal expansion, and severe electrical noise.
• High Efficiency: Powerful processor hardware ensures rapid screen switching, zero input latency, and seamless high-density graphic updates.
• Safety Protection: Built-in galvanically isolated communication lines shield sensitive internal logic from voltage spikes and ground loops.
• Energy Saving: Dimmable LED backlighting conserves overall electrical power and reduces cabinet heat dissipation.
• Easy Maintenance: Integrated system diagnostics and external memory media support allow rapid project updates and fast hardware servicing.

Applications

• Industrial: Heavy automated machinery, steel processing mills, chemical processing plants, and high-speed packaging networks.
• Factory: Textile dyeing and spinning facilities, pharmaceutical manufacturing lines, paper processing mills, and cement plants in Bangladesh.
• Commercial: Municipal water filtration plants, central HVAC building control grids, and power generation monitoring.
• Project Installation: Ideal large-format key panel choice for system integrators, control engineers, and OEM panel builders in BD.

Why Choose This Product?

• Siemens Comfort Quality: Built to international manufacturing standards, ensuring continuous 24/7 operational stability in demanding industrial plants.
• Superior Tactile Control: Physical membrane keys allow operators working with industrial gloves to enter numeric parameters quickly and accurately.
• Long-Term System Investment: High-resolution visualization and wide protocol compatibility safeguard your automation infrastructure investment.
• Trusted Local Value in BD: Verified product authenticity, technical specification support, and fast delivery across Bangladesh via LOOP Shop.

Technical Specification Table

Features List

• ✓ 15-inch widescreen TFT display with high-resolution visual rendering
• ✓ Integrated tactile system membrane keyboard with programmable function keys
• ✓ Dual PROFINET (Ethernet) and MPI/PROFIBUS DP communication ports
• ✓ IP65 rated dust and splash-proof front panel enclosure
• ✓ Configurable via WinCC Comfort V11 SP2 / V14 SP1 (TIA Portal)

Benefits For Customers

• Eliminates Manual Entry Errors: Tactile keypad feedback prevents input mistakes during parameter changes on the factory floor.
• Minimizes Operational Downtime: Clear real-time alarm histories and system diagnostics allow operators to fix machine faults rapidly.
• Enhances Process Monitoring: The expansive 15″ screen displays complex SCADA layouts and multiple trend graphs simultaneously.
• Resilient in Bangladesh Conditions: Robust IP65 front face withstands tropical humidity, dust, and factory floor challenges in BD.

Installation & Maintenance Guide

Installation Requirements:

1. Prepare a clean door cutout on the control enclosure according to Siemens KP1500 physical dimensions.
2. Fit the KP1500 Key Panel into the cutout from the front side and tighten all mounting clamps to form an airtight IP65 seal.
3. Wire a clean, regulated 24 V DC power supply feed to the main terminal block, ensuring secure earth grounding (PE).
4. Connect PROFINET Ethernet or PROFIBUS communication cables to their corresponding ports and secure retaining screws.

Maintenance Tips:

1. Clean the front display and membrane keyboard regularly using a soft, non-abrasive microfiber cloth; avoid aggressive chemical solvents.
2. Inspect cabinet ventilation and air filters periodically to maintain internal enclosure temperatures below 50 °C.
3. Keep physical communication cable connections tight to prevent vibration-induced signal dropouts.

Safety Instructions:

1. Always isolate incoming 24 V DC electrical power before installing, wiring, or servicing the HMI panel.
2. Verify correct supply voltage polarity before energizing the unit to prevent internal power board damage.
3. Press membrane keys using fingers or designated styluses; avoid using sharp metal tools or screwdrivers.

Frequently Asked Questions (FAQ)

Q: What is the price of Siemens SIMATIC KP1500 Comfort HMI 6AV2124-1QC02-0AX1 in Bangladesh?

A: Product pricing varies depending on stock availability, import tariffs, and market demand in BD. Please visit loopshop.com.bd or contact our team directly for updated pricing.

Q: Where can I buy original Siemens KP1500 Comfort HMI in Bangladesh?

A: You can purchase 100% genuine Siemens KP1500 Comfort key panels online directly from loopshop.com.bd with secure shipping across Dhaka, Chittagong, and all districts in BD.

Q: What warranty does this product come with?

A: This product carries standard supplier warranty coverage against factory defects. Please verify full terms with LOOP Shop upon order placement.

Q: Is the Siemens KP1500 Comfort suitable for Bangladesh climate conditions?

A: Yes, featuring an IP65 rated front face and an operating temperature ceiling up to 50 °C, it is engineered to operate dependably in tropical, humid, and dusty factory environments across BD.

Q: What engineering software is used to program the KP1500 Comfort panel?

A: The 6AV2124-1QC02-0AX1 model is configurable using Siemens WinCC Comfort V11 SP2 or from WinCC V14 SP1 and higher within the TIA Portal framework.

Q: What communication protocols are supported by this HMI?

A: It features dual onboard interfaces supporting both PROFINET (Ethernet) and MPI/PROFIBUS DP industrial fieldbus protocols.

Q: What is the screen size of the Siemens KP1500 Comfort panel?

A: It features a large 15-inch widescreen TFT display screen.

Q: Does this model feature physical keypad buttons?

A: Yes, the KP (Key Panel) designation indicates an integrated physical membrane system keyboard with tactile function and alphanumeric keys.

Q: Can this unit replace older KP1500 Comfort models?

A: Yes, the 6AV2124-1QC02-0AX1 serves as the official successor model for legacy KP1500 Comfort panels in standard control setups.

Q: Does LOOP Shop provide technical and specification support in BD?

A: Yes, LOOP Shop provides sales support, technical datasheet verification, and order fulfillment services across Bangladesh.
