Schneider ATV312HU15M2 1.5kW 2HP Single Phase VFD Drive

Description

The Schneider Electric Altivar 312 series variable speed drive (Model: ATV312HU15M2) is a high-performance single-phase AC drive designed to control 3-phase asynchronous electric motors rated up to 1.5kW (2HP). Operating from a standard 200V to 240V AC single-phase power supply with an apparent power capacity of 3.2kVA, it converts fixed utility power into high-precision variable frequency and voltage output for accurate motor velocity and torque regulation.

Engineered specifically for machine builders (OEMs), control panel integrators, and plant maintenance managers across Bangladesh, the ATV312HU15M2 features a compact 105mm width for flexible, space-saving mounting plate installation inside electrical control cabinets. Equipped with a bright 4-digit LED display, integrated EMC noise filtering, and a user-friendly jog dial navigation button, it delivers energy-efficient, reliable motor speed control using standard single-phase power lines.

Key Features

• Compact Plate Mounting Design: Features a compact 105mm width footprint allowing simple, space-saving mounting plate installation inside electrical cabinets.
• Bright 4-Digit LED Display: Built with a high-readability 4-digit LED interface and status/fault indicators for clear visibility of operational parameters and diagnostic codes.
• Intuitive Jog Dial Navigation: Features an integrated jog dial navigation wheel for rapid parameter tuning, menu selection, and quick setup.
• Integrated Class C2 EMC Filter: Embedded electromagnetic compatibility filter minimizes radio-frequency interference and line noise without requiring external filters.
• Multi-Protocol Communication Options: Supports Modbus RTU and CANopen communication natively, with optional expansion cards for Profibus DP, DeviceNet, Ethernet/IP, and Modbus TCP.
• Rugged Mechanical Construction: Constructed with heavy-duty heatsinks, durable industrial housing, and snap-lock seals to withstand harsh factory floor conditions.

Technical Advantages

• High Efficiency Operation: Delivers optimized energy conversion efficiency (~97%) under continuous full load, minimizing thermal dissipation inside enclosed control cabinets.
• Durable Construction: Heavy-duty aluminum heatsink design with forced convective cooling airflow ensures long operational life in enclosed control panels.
• Comprehensive Electrical Protection: Integrated protection against phase-to-phase short circuits, mains overvoltage/undervoltage, output phase loss, dynamic overcurrent, and thermal overload.
• Energy Savings: Automatically adjusts motor magnetizing current based on real-time load demands, lowering total kilowatt-hour (kWh) electricity usage.
• Simplified Maintenance: Clear visual diagnostic display, fault memory logging, and jog dial navigation streamline parameter backups, servicing, and troubleshooting.

Applications

• Industrial Manufacturing: Material handling conveyors, packaging equipment, automated strapping/packing machinery, and specialized textile equipment.
• Factory Automation: Plastic processing units, wire drawing machines, industrial mixers, mechanical actuators, and hoists.
• Commercial & HVAC: Industrial centrifugal exhaust fans, ventilation blowers, and water supply booster pumping systems.
• Project Installation: OEM control panel builder assemblies, sub-distribution control boxes, and equipment retrofits across Dhaka, Chittagong, and all over Bangladesh.

Why Choose This Product?

• Unmatched Reliability: Designed by Schneider Electric to conform to strict international standards (IEC/EN 61800-5-1, CE, UL, CSA, GOST).
• Superior Motor Performance: Delivers up to 170–200% dynamic starting torque at low speeds, preventing motor stalls under heavy starting loads.
• Cost Effectiveness: Allows running 3-phase 220V motors directly on a single-phase 220V power line connection, avoiding expensive 3-phase utility service installations.
• After-Sales Value: Supported locally in Bangladesh with standardized parameter structures, accessible replacement components, and local technical guidance.

Technical Specification Table

Features List

✓ 1.5kW (2HP) heavy-duty continuous output power capacity for 220V motors

✓ Single-phase 200–240V input to 3-phase output power conversion

✓ Bright 4-digit LED display with status display and intuitive jog dial button

✓ Integrated Class C2 EMC filter for low electromagnetic noise interference

✓ Supports Modbus RTU and CANopen communication protocols

✓ Heavy-duty cooling design supporting up to 50°C ambient temperatures

Benefits For Customers

• Reduces Electricity Cost: Soft start-up and partial load current optimization lower power draw, reducing monthly facility electric bills.
• Improves Operational Reliability: Prevents sudden mechanical jolts on motor shafts, couplings, and drive belts during acceleration.
• Saves Maintenance Cost: Smooth motor torque control reduces mechanical wear and tear, prolonging machine service intervals.
• Suitable for Bangladesh Environment: Designed to withstand high ambient temperatures up to 50°C and input line voltage variations.

Installation & Maintenance Guide

Installation Requirements:

1. Mounting Position: Install vertically on a flat, heat-resistant mounting plate inside an appropriately ventilated industrial control cabinet.
2. Clearance Spacing: Maintain a minimum vertical clearance of 100mm above and below the drive for convective cooling airflow through the heatsink.
3. Power Wiring: Wire single-phase incoming main power (L1, L2/N) through an appropriately rated circuit breaker (MCB/MCCB) and fast-acting semiconductor fuses. Wire output motor terminals (U/T1, V/T2, W/T3) using shielded 4-core copper power cables.
4. Earthing/Grounding: Ensure low-impedance ground bonding between the drive PE ground terminal, cabinet backplate, and motor frame.

Maintenance Tips:

• Dust Management: Blow clean, dry compressed air (max 2 bar) through the heatsink cooling fins every 3–6 months to prevent thermal accumulation.
• Cooling Fan Inspection: Periodically check that internal cooling fans spin freely without unusual acoustic noise or friction.
• Terminal Verification: Retighten all power and control screw terminals during routine maintenance to prevent loose, high-resistance hot spots.

Safety Instructions:

• Capacitor Discharge: Disconnect all main power sources and wait at least 15 minutes before touching electrical terminals to allow high-voltage DC bus capacitors to fully discharge.
• Insulation Testing: Never perform Megger high-voltage insulation tests directly on VFD terminals; disconnect motor leads completely prior to testing motor insulation resistance.

Frequently Asked Questions (FAQ)

Q: What is the price of Schneider ATV312HU15M2 1.5kW VFD in Bangladesh?

A: The price of the Schneider ATV312HU15M2 1.5kW 2HP single-phase VFD in Bangladesh depends on import taxes, stock availability, and exchange rates. Check live pricing listed above on loopshop.com.bd or contact our sales team for a quote.

Q: Where can I buy original Schneider ATV312HU15M2 VFD in Dhaka, Bangladesh?

A: You can purchase genuine Schneider Electric ATV312HU15M2 VFDs online directly at loopshop.com.bd with guaranteed product authenticity, invoice, and fast delivery across Dhaka and all over Bangladesh.

Q: Can I run a 3-phase motor using single-phase 220V power with this VFD?

A: Yes, the ATV312HU15M2 converts 200–240V single-phase power input into balanced 3-phase 220V output to operate standard 1.5kW (2HP) 3-phase induction motors (wired in delta configuration).

Q: What warranty does this product have on loopshop.com.bd?

A: Standard manufacturer line warranty or seller warranty terms apply at the time of purchase. Please check with loopshop.com.bd customer service to verify current warranty conditions.

Q: Is the Schneider ATV312HU15M2 suitable for Bangladesh climate conditions?

A: Yes, it is built with high-grade industrial components rated to operate reliably in ambient temperatures up to 50°C without derating, making it well-suited for Bangladeshi factory conditions.

Q: How do I adjust motor speed on this drive?

A: Motor speed can be controlled using the onboard jog dial navigation button, an external 0–10V potentiometer, 4–20mA current loop signal, multi-speed digital inputs, or Modbus RTU / CANopen serial communication from a PLC or HMI.

Q: What is the rated capacity of the ATV312HU15M2 drive?

A: The drive is rated for 1.5kW (2HP) output power with a 3.2kVA apparent power rating under 200–240V single-phase AC operation.

Q: Does the ATV312HU15M2 include an integrated EMC filter?

A: Yes, it comes equipped with an integrated Class C2 EMC filter to suppress radio-frequency interference and line noise.

Q: How to install this product safely in an electrical panel?

A: Mount vertically inside a ventilated cabinet, maintaining clear top and bottom airflow. Wire single-phase main power to L1/L2 and motor wires to U/V/W according to Schneider wiring schematics while securing ground grounding.

Q: What industrial applications are best suited for this 1.5kW single-phase drive?

A: It is ideal for industrial machinery including packaging equipment, material handling conveyors, textile machines, water supply booster pumps, and exhaust ventilation fans operating on 220V single-phase lines.
