Description
The Mitsubishi Electric GT1695M-XTBA GOT1000 Series Touchscreen HMI (15-Inch) is a high-end Human Machine Interface engineered for complex industrial automation, high-level machine visualization, and process control. Featuring a spacious 15-inch high-resolution graphical display, this panel allows operators to oversee multi-stage production processes with maximum visual clarity.
By translating complex PLC network telemetry into intuitive graphics, dynamic trend charts, and immediate alarm notifications, the GT1695M-XTBA simplifies operational workflows. Factory managers, automation engineers, and machine operators across Bangladesh rely on this panel for central control desks, machinery retrofits, and non-stop industrial runtime.
Key Features
- 15-Inch High-Resolution Display: Large graphical screen format allows comprehensive multi-loop process layouts to be displayed on a single screen.
- Precision Touchscreen Interface: Highly responsive touchscreen overlay designed for fast, accurate parameter adjustments and screen navigation.
- Multi-Protocol Fieldbus Support: Built-in communication options for Mitsubishi MELSEC PLCs and third-party industrial network devices.
- Advanced Alarm & Data Logging: Supports real-time alarm reporting, dynamic trend plotting, recipe selection, and system diagnostics.
- Rugged Front Panel: IP65-rated front casing protected against heavy dust, grime, and liquid splashes in factory environments.
- GT Works3 Engineering: Fully configurable using Mitsubishi Electric GT Works3 (GT Designer3) software.
Technical Advantages
- Durable Construction: Industrial-grade housing engineered to withstand continuous physical touch input, mechanical vibration, and thermal shifts.
- High Efficiency Data Handling: Powerful internal processing engine prevents display lag during high-speed real-time data updates.
- Easy Maintenance: Simplifies diagnostic troubleshooting through clear graphical fault logs, minimizing factory downtime.
- Enhanced System Security: Multi-tier password administration protects critical system settings against unauthorized tampering.
Applications
- Industrial Facilities: Centralized machine control panels, automated assembly lines, packaging plants, and material handling systems.
- Factory Environments: Textile spinning and dyeing machinery, garment finishing equipment, food processing lines, and chemical plants.
- Commercial & Utility Projects: Water treatment plants, central HVAC monitoring units, and power distribution control desks.
- Project Installation: Ideal for machine OEMs, integrators, and plant engineers upgrading complex machine panels across Bangladesh.
Why Choose This Product?
- World-Class Mitsubishi Reliability: Proven GOT1000 platform guarantees stable, long-term continuous operation in demanding plant environments.
- Comprehensive Operator Control: Spacious 15-inch display format reduces navigation steps, lowering operator error and speeding up setup.
- High ROI & Service Life: Minimizes operational downtime and lowers maintenance overhead over years of continuous service.
- Trusted Local Sourcing: Sourced with technical precision and backed by nationwide delivery through LOOP Shop in Bangladesh.
Technical Specification Table
| Specification |
Details |
| Model |
GT1695M-XTBA |
| Brand |
Mitsubishi Electric |
| Series |
GOT1000 Series |
| Display Size |
15.0 Inch |
| Display Type |
TFT Color Display |
| Operation Type |
Touchscreen |
| Rated Power |
Not Available |
| Voltage |
100-240 V AC |
| Current |
Not Available |
| Frequency |
50/60 Hz |
| Efficiency |
High-efficiency industrial graphical display |
| Protection |
IP65 (Front) / IP20 (Rear) |
| Dimension |
Not Available |
| Weight |
Not Available |
| Operating Temperature |
0 °C to +52 °C |
| Warranty |
Standard Manufacturer Warranty |
Features List
- ✓ 15-inch high-resolution graphical touchscreen display
- ✓ Smooth, responsive touch screen interface
- ✓ Native communication support for Mitsubishi MELSEC PLCs
- ✓ Advanced alarm logging, recipe handling, and graphical trend charts
- ✓ Front panel IP65 protected against dust and moisture
- ✓ Configurable via Mitsubishi GT Works3 (GT Designer3) software
Benefits For Customers
- Improves Operational Reliability: Large visual layout gives operators a complete view of machine status to prevent production errors.
- Reduces Maintenance Cost: Robust industrial construction lowers component failure rates and minimizes service overhead.
- Enhances Productivity: Fast screen transitions and clear diagnostic alarms speed up machine troubleshooting.
- Suitable for Bangladesh Environment: Operates reliably under high ambient factory temperatures (up to 52 °C) common in BD.
Installation & Maintenance Guide
Installation Requirements:
- Prepare a clean vertical cutout on the control cabinet door matching GT1695M-XTBA mounting frame dimensions.
- Maintain at least 10 mm clear ventilation space around the rear chassis for adequate air dissipation.
- Connect to a stable 100-240 V AC main power supply line equipped with appropriate circuit protection and grounding.
Maintenance Tips:
- Gently clean the touchscreen front panel using a soft, dry, non-abrasive cloth; avoid aggressive chemical solvents.
- Inspect terminal blocks, grounding leads, and communication cables periodically for tight signal contact.
- Maintain updated digital backups of panel runtime projects on your engineering station or external media.
Safety Instructions:
- Always disconnect main line power before mounting, wiring, or servicing the HMI unit.
- Connect the dedicated grounding terminal securely to shield internal electronics against static charges and line noise.
Frequently Asked Questions (FAQ)
Q: What is the price of Mitsubishi GT1695M-XTBA HMI in Bangladesh?
A: For live stock updates, competitive pricing, and official commercial quotes in BD, please visit loopshop.com.bd or contact our customer sales team.
Q: Where can I buy original Mitsubishi GT1695M-XTBA in Bangladesh?
A: You can purchase genuine Mitsubishi GOT1000 HMI panels online directly from LOOP Shop at loopshop.com.bd.
Q: What is the display size of the Mitsubishi GT1695M-XTBA?
A: This model features a 15.0-inch graphical touchscreen display panel.
Q: Which software is used to program the GT1695M-XTBA HMI?
A: Mitsubishi GOT1000 series HMIs are engineered using Mitsubishi GT Works3 (GT Designer3) software.
Q: What power voltage does this panel require?
A: The GT1695M-XTBA operates on a standard 100-240 V AC supply voltage.
Q: What warranty does this product have?
A: Standard supplier/manufacturer warranty terms apply when purchased through LOOP Shop. Contact our support team for specific terms.
Q: Is this HMI panel suitable for Bangladesh factory conditions?
A: Yes, with an IP65 rated front panel and operating temperature tolerance up to 52 °C, it performs reliably in local factory environments.
Q: How to install this product?
A: Cut out the designated opening on your cabinet door, insert the HMI unit, clamp it securely from the rear, and wire the AC power and communication lines.
Q: Can this HMI connect to non-Mitsubishi PLCs?
A: Yes, Mitsubishi GOT1000 HMIs support communication protocols for various third-party PLC manufacturers alongside native MELSEC connectivity.
Q: Does LOOP Shop deliver across all districts in Bangladesh?
A: Yes, LOOP Shop provides nationwide delivery to all major districts and industrial zones across Bangladesh.
