Description
The CompAir L23–L29 RS Series comprises oil-lubricated rotary screw compressors designed for industrial applications requiring reliable and efficient compressed air supply. These compressors, ranging from 23 to 29 kW, are available in both fixed and regulated speed (RS) models, offering flexibility to match varying operational demands.
🔧 Key Specifications
- Power Range: 23 to 29 kW
- Free Air Delivery (FAD): Up to 5.52 m³/min (194.94 cfm)
- Pressure Range: 5 to 13 bar (72.5 to 188.5 psi)
- Cooling System: Air-cooled
- Noise Level: Low-noise operation suitable for indoor environments
- Dimensions: Approximately 1,675 mm (L) x 880 mm (W) x 1,612 mm (H)
- Weight: Approximately 902 kg
🛠️ Notable Features
- Premium Efficiency Airend: In-house designed semi-integrated airend with slow rotational speed reduces energy costs and enhances reliability.
- High-Efficiency IE3 Electric Motor: Standard inclusion of IE3 class motors ensures energy-saving performance.
- Delcos Pro SE Controller: Advanced controller with features like discharge/line pressure display, air/oil temperature monitoring, service indicators, fault log, real-time clock, remote start/stop, auto-restart after power failure, and RS485 – Modbus RTU communication.
- Integrated Heat Recovery System: Available option to recover up to 94% of the energy used, improving overall efficiency.
- High-Performance Separator Filtration: Ensures high-quality air with less than 3 ppm oil carryover.
- Thermostatically Controlled Motor-Driven Fan: Allows compressor operation in the workplace and supports maximum duct length without additional assistance.
- Easy Maintenance & Service: Design facilitates quick service with optimized service parts like separators and filters.
📦 Applications
These compressors are ideal for various industrial sectors, including:
- Automotive manufacturing
- Food and beverage processing
- Pharmaceutical production
- Chemical industries
- General manufacturing
