5 KW Solar On Grid Inverter

Description

Solis 5 kW On-Grid Solar Inverter – Key Specifications

• Model: Solis S6-GR1P5K​
• Type: Single-phase, grid-tied
• Rated AC Output Power: 5,000 W​
• Maximum AC Output Power: 5,500 W​
• Maximum Efficiency: 97.7%​
• Ingress Protection: IP66 (suitable for outdoor installation)​
• Dimensions (W × H × D): 310 × 543 × 160 mm​
• Weight: 12 kg​
• Operating Temperature Range: -25°C to +60°C​
• Cooling Method: Natural convection​
• Warranty: 5 years standard (extendable options available)​

 DC Input (PV Side)

• Maximum PV Input Power: 7,500 W ​
•  Maximum DC Voltage: 600 V
• Start-up Voltage: 120 V
• MPPT Voltage Range: 90–520 V​
• Number of MPPTs / Strings per MPPT:2 / 1
• Maximum Input Current per MPPT: 14 A​
• Maximum Short-Circuit Current per MPPT: 22 A​

  AC Output (Grid Side)

• Rated Output Voltage: 220–230 V​
• Rated Frequency: 50/60 Hz​
• Rated Output Current: 7 A / 21.7 A​
• Maximum Output Current: 0 A​
• Power Factor:99 (adjustable from 0.8 leading to 0.8 lagging)
• Total Harmonic Distortion (THD): <3%
